污水處理廠污泥獨立焚燒的熱力計算方法解析
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第37卷 期數: 2021年第16期 頁碼: 83-88 欄目: 出版日期: 2021-08-17
Title:Analysis of Sewage Sludge Mono-incineration Thermodynamic Calculation Method in a Sewage Treatment Plant
作者:段妮娜，譚學軍，張辰(上海市政工程設計研究總院<集團>有限公司，上海200092)
Author(s):DUAN Ni-na,TAN Xue-jun,ZHANG Chen(Shanghai Municipal Engineering Design Institute Co. Ltd.， Shanghai 200092， China)
關鍵詞:污泥焚燒; 獨立焚燒; 熱力計算
Keywords:sludge incineration; mono-incineration; thermodynamic calculation
摘要:污泥焚燒作為城鎮污水廠污泥處理的主流技術之一，在我國得到越來越多的工程化應用，現階段我國污泥焚燒在進行工藝設計和運行情況模擬時，計算污泥（燃料）發熱量、煙氣組成和焓值等關鍵環節，多借鑒燃煤鍋爐的熱力計算方法。熱力計算是工藝設計和工藝運行時模擬預測的基本依據，作為工藝設計過程的重要內容，其方法的修正和完善有利于提升工藝設計和運行調控的準確性和合理性。污泥焚燒與燃煤鍋爐燃燒過程和控制要點均有差異，燃煤鍋爐計算方法忽略了煙氣中水蒸氣的潛熱，故采用燃煤鍋爐熱力計算方法的準確度有待驗證。分別采用傳統燃煤鍋爐的熱力計算方法和優化后的方法進行了計算示例比較，當采用燃煤鍋爐的熱力計算方法進行污泥焚燒的工藝計算時，由于未考慮煙氣中水蒸氣的實際狀態和潛熱，影響焚燒爐燃燒溫度、煙氣余熱利用和煙氣凈化各環節的溫度預測的精確度。我國污泥焚燒入爐含水率的常見區間為50%~60%，采用傳統方法計算時，從燃燒溫度到后續煙氣設施對應的入口和出口溫度均偏高40~50 ℃。當采用傳統方法進行設計和運行時，應結合入爐含水率的選擇，充分考慮到由此引起的偏差。
Abstract:Sludge incineration, as one of the main sludge treatment technologies in urban sewage treatment plants, has been widely applied in engineering in China. At present, coal-fired boiler thermodynamic calculation method is often referred to calculate the key parameters (such as calorific value of sludge or fuel, composition of flue gas and enthalpy value) in the process of design and simulation. Thermal calculation is the basis of process design and simulation. As an important part of process design, modification and improvement of the method is beneficial to improve the accuracy and rationality of process design and management. There are differences in the incineration process and management between sewage sludge and coal incineration in coal-fired boilers. The calculation method of coal-fired boilers ignores the latent heat of water vapor in flue gas, so the accuracy of coal-fired boiler thermal calculation method needs to be verified. A comparison between the traditional thermal calculation method and the optimized thermal calculation method was exemplified. The actual state and latent heat of water vapor in flue gas were not considered when the coal-fired boiler thermal calculation method was used for sludge incineration process calculation, which affected the temperature prediction accuracy of incinerator combustion, flue gas waste heat utilization and flue gas purification. Common range of sludge water content to be combusted in the furnace in China is 50%-60%. The combustion temperature and the corresponding inlet and outlet temperature of flue gas facilities were 40-50 ℃ higher when the traditional method was employed. When the traditional method is used for design and operation, the deviation caused by calculation should be fully considered in combination with the selection of sludge water content to be combusted in the furnace.
